Weight (RTM + Transp. Case) (kg) 11.2
Non-Accuracy Max ( ± % of Cal. Cap.) 3 3 3 3
Non-Accuracy Max ( ± % of Max.Cap.) 2 2 2 2
Temperature range ambient (
°
C) –20
°
C — +60
°
C
Display LCD 0 — 19999
Digit size (mm) 12
Battery life-time (hours) 25 (Alkaline 9V battery 6LR61)
Sealing class IP 65
3 RTM 20 D Main parts
1 Tightening device 8 Display
2 Clamping jaw 9 Pull rod
3 Tightening screw 10 Leaf spring unit
4 Centre support ( flat) 11 Load cell
5 Outer rope support 12 Battery unit
6 Electronic unit 13 Battery unit opening
7 Push buttons 14
