Brookfield Engineering Labs., Inc. Page 38 Manual No. M08-218-B0212
=storing
Name: C50-1/30
tau_prom: 01.1418
k_gamma: 01.2910
Use the OK key to store the new information, otherwise press the ST key to return to the
menu without storing.
VI.6.5 Utilities → Print Memory
This function allows the output of the data stored in the instrument memory to either a printer
or to the RS232 serial interface of the rheometer.
The instrument will prompt you to select the output device, as follows:
Sel. output-device:
-Printer
-RS232
a) Output to printer:
The printer must be connected to the rheometer and ready for operation.
b) Output to the RS232 serial interface:
The data receiving side (typically a PC) must be set to the data transfer parameters
from the rheometer. If the receiving side is not set up properly, the data will either not
be transmitted or transmitted to Null. (see Section VI.8: Serial Data Transfer via the
RS232 Interface ).
After choosing the output device, you are prompted to select the program to be printed or
transferred.
Date of Measurement
Select Program:
-1)17.10;11:20
-2)17.10;12:30
-3)17.10;13:40
Meas. Series Counter
MEASCOUNT
Time of Measurement
The data of the program will print as a table to a printer or will be transferred via the serial
interface. After completion of data transfer, the rheometer returns to the Utilities Menu.
VI.6.6 Utilities →Clear Memory
This function deletes all measured data stored in the memory of the R/S-CPS+ Rheom-
eter.
