AIP-W525H
- 4 -
1.3 Panel Layout
1.3.1 The Front Panel
Figure 1-1 Front Panel sketch
The Router’s LEDs and the WPS/Reset Button are located on the front panel (View from left to
right).
Name Status Indication
PWR
Off Power is off.
On Power is on.
SYS On Push the Reset button
WLAN
Off The Wireless function is disabled or not active
Flashing The Wireless active
WAN,
1,2,3,4 (LAN)
Off There is no device linked to the corresponding port.
On
There is a device linked to the corresponding port but
there is no activity.
Flashing There is an active device linked to the corresponding port.
WPS
Slow Flash
A wireless device is connected to the network by WPS
function. This process will last for about 2 minutes.
On
A wireless device has been successfully added to the
network by WPS function. The LED will light up for about
5 minutes.
Quick Flash
A wireless device failed to be added to the network by
WPS function.
Table 1-1 The LEDs Description

Note:
1. After the device has been successfully added to the network by the WPS function, the WPS
LED will light up for about 5 minutes and then turn off.
2. To reset the router, press the WPS/Reset Button and hold for more than five seconds.
