AIP-W525H
- 21 -

Note:
1. If you change the IP Address of LAN, you must use the new IP Address to log into the Router.
2. If the new LAN IP Address you set is not in the same subnet, the IP Address pool of the DHCP
server will change accordingly at the same time，while the Virtual Server and DMZ Host will
not take effect until they have been re-configured.
 Default Gateway - Enter the gateway IP address in dotted-decimal notation provided by your
system administrator.
 DHCP – Select Disabled, Client or Server in different operation mode for AIP-W525H
 DHCP Client Range - Fill in the start IP address and end IP address to allocate a range of IP
addresses; client with DHCP function set will be assigned an IP address automatically.
 Show Client – Press open to active the DHCP Client Table window that shows the active
clients with their assigned IP address, MAC address and time expired information. [Server
mode only]
 DHCP Lease Time – Amount of time the IP address is leased for.
 Set Static DHCP - Manual setup Static DHCP IP address for specific MAC address. [Server
mode only]
 Domain Name - Assign Domain Name and dispatch to DHCP clients [optional]
 802.1d Spanning Tree - Enable or disable the IEEE 802.1d Spanning Tree function from
pull-down menu.
 Clone MAC Address - Fill in the MAC address for the MAC address to be cloned.
