ALFA NETWORK AIP-W525H - Manual (Page 44)

AIP-W525H
- 39 -
4.6.5 WDS Settings
Choose menu “Wireless → WDS Settings”, you can configure the advanced settings of your
wireless network.
Figure 4-24 Wireless Advanced
To add wireless AP by MAC Address, click Enable WDS.
 MAC Address - The wireless station's MAC address that you want to add.
 Data Rate - Select transmission data rate from the drop down menu. Data rate can be
auto-selected, 1Mbps to 54Mbps or MCS.
 Set Security - There are two wireless security modes supported by the WDS: WEP (Wired
Equivalent Privacy), and WPA2 (Wi-Fi Protected Access 2).
 Encryption – Use drop down menu to configure WDS security, you can select it from
None, WEP 64-bits, WEP 128-bits, or WPA2 (AES).
