Page 36 MAXX 2400 Owners Manual
D. The Channel 1 transport Window will display the words IDLE CUEING for two seconds or
less. When ready to record, the Channel 1 Transport Window will display IDLE READY per
Figure 13.
Figure 13 - Channel 1 Ready To Record
E. You may now click the RECORD button at any time to begin recording. The yellow time
display counters will update the clip duration continually.
F. To stop recording, click STOP.
Note: An in-progress recording must be at least 10 seconds long before it will appear in the clip
list. Hitting the STOP button to end the recording after less than 10 seconds will also cause the clip
to appear in the clip list
