Clearing a Document Jam
If a document becomes Jammed in the machine, the display wilt show the informa
tion code 031.
To clear the jam,
1
.
Open the Receiving Unit (Control Panel) by
pulling the latch button forward on the right
side panel, and swing the Receiving Unit
forward. Remove the recording paper.
Receiving Unit
Latch Button
2
.
Unlock the Document Scanning Guide by
gently pressing inward on the two tabs
located at the right and left ends of the unit
and swing the Document Scanning Guide
forward.
3. Remove the jammed paper.
Document
Scanning
Guide
4»
Relock the Document Scanning Guide into
place by gently pressing backward until it
clicks. Reset the recording paper correctly
(see page 62), then gently close the
Receiving Unit with both hands. Tear the
recording paper projecting from the unit.
