Location of Controls
(Remote and Receiver)
Front Control Panel for Some Models
POWER «VOL
Ó
POWER
Front Control Panel for Some Models
4 VOLUME»
'CHANNELA ACTION TV/VIDEO
qp Qp 9 C
Ó © ©
0
©
Oh
© © ©L
L©_ © ®J
R-TUNE 1 I RECALL
-O © O-
Remote Conlrol
Sensor
IVCR POWER re C
I
n
REU
TV/rACT F PO^EH '
STOP PLAY FT n
©
cm CE]
TV/VCR VCR CHANNEL PAUSE
O ® CD O
©
Í13
Quick Reference Control Operation
Power Button - Press to turn ON or OFF (pg 10)
V d I (Volume) Buttons - Press to adjust Sound Level Press to adjust
Audio Menus, Video Menus and select operating features when menus
are displayed (pg 10)
Ch (Channel) Buttons - Press to select programmed channels Press to
highlight desired features when menus are displayed Also used to select
Cable Converter box channels after programming Remote Control
Infrared codes (the TV/CABLE switch must be set in CABLE position)
(pgio)
Action Button - Press to display Mam Menu and access On Screen feature
and Adjustment Menus (pg 12)
TV/Video Button - Press to select TV or Video Input (pg 11) Remote Control
Multi Button - Programmable to operate up to six Remote Function buttons (pg 11)
Mute Button - Press to mute sound A second press returns sound (pg 10)
R-Tune (Rapid TUne) Button - Press to switch between two channels (pg 10)
Recall Button - Press to display Time, status of Sleep Timer, Channel, Video Mode, Channel Caption and Audio
Mode (pg 11)
Keyboard "0 through 9” Buttons - Press desired channel number to access any channel(pg 10)
VCR Function Buttons - Programmable to operate many brands of VCRs The TV/CABLE switch must be set in
TV position (pg 10)
Cable Power Button - Programmable to operate selected CATV converter boxes (pg 11)
Ti) TV/Cable Switch - This switch is used to select the proper mode when programming Remote Control Infrared
codes or operating the TV or external equipment (VCR or Cable Converter box)
