Antenna/CableConnectìons
Anienna Connectian - For proper reception of VHF/UHF channels an external
antenna is required For best reception an outdoor antenna is recommended
Antenna Mode must be set to TV (Refer to Antenna Mode section )
Incoming Cable From Home Antenna (75 Ohm)
VHF/UHF
□ n
Back
□ [ S
b
I
n
Typical VHF/UHF Antenna
Incoming Cable From Home Antenna (300 Ohm)
VHF/UHF
□n Back S
b
I
300 !□ 75 ohm Matching
TransfarmBr(Nal IncludBd)
Cable Conneclion - For reception of cable channels (01-125) connect the cable supplied by your local cable company
Antenna Mode must be sel to CABLE (Refer to Antenna Mode section )
Incoming 75 Ohm Cable (From Cable Company)
VHF/UHF
□n Back
b
T S
b
I
o
NOTE: Certain cable systems offset some channels to reduce interference or have Premium (scrambled) channels A
cable converter box is required for proper reception Check with your local Cable company for its compatibility
requirements
Other Video Equipment
VCRs, Video Disc Players, Computers, TV games and Teletext equipment can also be connected to the antenna input
connection
-G-
