Specifications
CRT Size 21
"
CRT (20.0"
/
50.8 cm Viewable Image Size) Flat Square
Dot-pitch 0.25 mm (Horizontal: 0.217mm
/
Vertical: 0.132mm)
Phosphor
/
Glass RGB medium short persistence (Hi-EU RED), Crystal Pigment
/
Dark tint
Surface treatment B-AGRAS (Anti-Glare, antÍ-ReflectÍve and Anti-Static) Coat
Input signals Video signaling RGB analog
Signal level 0.7 Vp-p (without sync, signal), 1.0 Vp-p (with sync, signal)
Sync, signal H
/
V separation (TTL level), H
/
V composition (TTL level),
Sync.-on-green
Frequency Range Horizontal Frequency : 30.0 kHz to 117.0 kHz*
Vertical Frequency : 50.0 Hz to 180.0 Hz
Preset mode 1 preset and 7 reservation (See page 15)
Video Maximum Pixel Clock 250.0 MHz (typ.)
Resolution 1,600 dots (H) X 1 ,200 lines (V) at 92 Hz, 1,800 dots (H) x l ,440 lines (V) at 70 Hz*
Viewable Image Size Factory preset
(H X V, Diagonal) Full scan (Typical)
15.59" X11.69", 19.5" Diagonal
**
15.98" X 11.97", 20.0" Diagonal
”
Display Color Analog input, unlimited number of colors
***
Connectors Video Signal 15 pin mini D-Sub connector (female pins), BNC x 5
Power supply CEE-22 type 3-pin connector
Input power 100 to 240 V AC (50 or 60Hz)
Power consumption 148 W typ.
/
< 10 W stand-by, < 3 W sleep mode (See page 14)
Controls Front Power ON
/
OFF, [0, H, H, H] keys
On screen display Contrast, Brightness, Size & Pos. (Zoom, H. Position, H. Size,
V. Position, V. Size), Geometry (V. Pincushion, Side Pin. Bal.,
Trapezoid, Parallelogram, Top Comer, Bottom Corner, S-Curve 1,
S-Curve 2), Rotation (Tilt), Color Temp. (9300K + 8 MPCD, 7500
K, 6500 K, 5000 K, 9300 K -t- 27 MPCD, User), Recall, Video Level
(0.7 V
/
1 V), H. Moire, V. Moire, H.Convergence, V.Convergence,
Linearity-C, Linearity-E, Language, OSD Position, Degauss, Signal,
Self-Test menu
Tilt
/
swivel 13° up, 3° down, 90° each to right and left
Dimensions (W x H x D) 19.6" X 18.8" X 19.5"
(498 mm x 477.5 mm x 494.5 mm)
Weight (monitor only) 27.0 kg (59.5 lbs)
Approvals UL1950, CSA 22.2 No.950, TÜV
/
GS, CE
/
CISPR 22-B (EN55022),
NORDIC, FCC Class B, DHHS, HC, IC-B, VCCI Class B,
MPR II, TCO'92,
E nergy
S tar I®, ISO 9241-3 (Ergonomics)
/
-8 (Colors)
Standard 1 detachable signal cable for VGA, SVGA
1 detachable AC power supply cord
Tilt & Swivel base attached
Operating Instructions, Warranty card
Environmental conditions Operating Temperature 5 to 35 ’C(41 to 95 T)
Humidity 5 to 90% (no condensation)
Altitude 10,000 ft
Storage Temperature -20 to -r-60 *C (-4 to 140 °F)
Humidity 5 to 90% (no condensation)
Altitude 40,000 ft
Windows® 95
/
98 Plug & Play VESA® DDC™ 1
/
2B meets Windows® 95
/
98 Plug & Play
Requirements
Note;
• The on-screen image may flicker if the display is operated with the Vertical freq. under 60 Hz.
* FCC Class B Complied : Up to Mode 1,600 x 1,200 at 115 kHz max. and 1,800 x 1,440 at 105 kHz max. Horizontal
frequency,
** Depends on signal timing used, see page 15.
*** Number of colors depends on the Video Board used, memory installed, and RAMDAC (Random Access Memory
Digital to Analog Converter),
Specifications and design are subject to change without notice.
This product may be subject to export control regulations. Weight and dimensions shown are approximate.
