Adjustments
Adjustments menu
3 Contrast Adjust the screen contrast to match the brightness level in the room.
Pressing the [ 2 ] key toggles between brightness and contrast.
Direct operation]
Even if the menu screen does not appear, the contrast can be adjusted by pressing
the H or B key. If the 3 and B keys are pressed at the same time, the
maximum level (100) will be set.
Brightness ! Adjust the brightness to match the brightness level in the room so that the level
will be easy to see.
Pressing the [D key toggles between contrast and brightness.
Note; If the 3 and B keys are pressed at the same time on the Brightness
adjustment screen, the standard level (50) wilt be set.
Size
&
Pos.
! Press the { 2} key to select the zoom / horizontal position / horizontal size / vertical
position / vertical size adjustments.
Press the (T| key to save the adjustment.
Zoom
! Both the horizontal and vertical size of the image can be adjusted at the same
time; however, the aspect ratio cannot be changed.
Press the 3 key to make the image smaller, the B key to make it larger.
H. Position
! The horizontal position of the image can be adjusted.
Press the 3 key to move it to the left, the B key to move it to the right.
H H. Size ! The horizontal size of the image can be adjusted.
Press the 3 key to make the image smaller, the B key to make it larger.
Note: Setting the image in the center of the screen to start will make the
adjustment easier.
V. Position ! The vertical position of the image can be adjusted.
Press the 3 key to make it downward, the B key to move it upward.
m V. Size ! The vertical size of the image can be adjusted.
Press the 3 key to make the image smaller, the B key to make it larger.
Note: Setting the image in the center of the screen to start will make the
adjustment easier.
1) u Geometry : Press the [ 2 ] key to select the vertical pincushion / side pincushion balance I
trapezoid / parallelogram / Geometry 2 adjustments.
Press the Q] key to save the adjustment.
O V. Pincushion !
The image can be corrected for barrel distortion.
Press the 3 key to decrease the Pin / Barrel distortion of the image,
the B key to increase it.
n Side Pin. Bal. !
It is possible to adjust the side pincushion balance to the left and right.
Press the 3 key to expand to the left of the image, the B key to
expand it to the right.
f~\ Trapezoid !The image can be corrected for trapezoidal distortion.
Press the 3 key to make the top edge narrower, the B key to make the
___ bottom edge narrower.
/~7 Parallelogram iThe image can be corrected for parallelogram distortion.
Press the 3 key to collapse the parallelogram to the left, the B key
to collapse it to the right.
^ h Geometry
2
;
Press the B key to change the sub OSD screen.
Press the [H key to select the Top Corner / Bottom Corner / S-Curve 1 /
S-Curve 2 adjustments.
O Top Corner !
The image can be corrected for vertical pincushion distortion in the
top corner.
) I Bottom Corner ! The image can be corrected for vertical pincushion distortion in
the bottom corner.
51
S-Curve 1 ! The image can be corrected for vertical pincushion distortion in the S-
Curve 1.
L_i
52
S-Curve 2 ! The image can be corrected for vertical pincushion distortion in the S-
Curve 2.
I__ I <^\______ 1
