Adjustments (Continued)
Adjustments menu
Signal ! Use the S and B keys to select either the rear panel input terminal port A
(Mini D-Sub type) or Port B (BNC) type.
This displays the input synchronization signal frequency.
Information on the input screen mode (resolution, horizontal and vertical
synchronization frequency) will be displayed on the display monitor. There are
occasions sometimes when some screen modes in use do not display any
resolution. Direct display allows this to be displayed on screen by pressing
the \J} key even when the menu screen is not displayed.
Self-Test menu (No Signal screen)
This display indicates that the monitor is operating normally. When one of the following
conditions occurs, press one of the 4 operation keys to call the appropriate display.
N o S i g n a l
f H — . — k H z
f V — . — H z
P o r t ^ - 0 -
E r r o r
f H 1 1 9 . 0 k H z
f V 1 9 0 . 0 H z
P o r t ^ - O -
No signal (the computer is not connected,
the mains power to the computer is
disconnected or the input connector in
use may be deselected, see Page 13
Signal for instructions.)
The horizontal or vertical sync, signal are
outside of the permitted range (the value of
the horizontal sync, signal will be displayed
in red and the value of the vertical sync,
signal will be displayed in white.)
