Specifications
NV-F55EA
I Power Source;
• Power Consumption:
Information for Your Safety
230 V AC 50-60HZ
28 watts
Video Recording System:
Video Heads:
Tape Speed:
Tape Format:
Record/Playback Time:
FF/REW Time:
VIDEO
Teievision System:
Moduiation System:
Input Level:
Output Level:
AUDIO
Input Level:
Output Level:
Audio Track:
Video Horizontal Resolution:
Signal-to-Noi$e Ratio:
Dynamic Range:
Audio Frequency Response:
Wow and Flutter:
Operating Temperature:
Operating Humidity:
Weight:
Dimensions:
Standard Accessories:
2 rotary heads, helical scanning system
4 heads
SP; 23.39 mm/sec.
LP; 11.7 mm/sec.
VHS tape
SP; 240 min. with NV-E240
LP; 480 min. with NV-E240
Approx. 2.5 min. with NV-E180
CCIR; 625 lines, 50 fields, PAL colour signal
ElA; Standard (525 lines, 60 fields), NTSC colour signal
Luminance; FM azimuth recording
Colour signal; converted subcarrier phase shift recording
VIDEO IN (PHONO); 1.0 Vp-p,
VIDEO OUT (PHONO); 1.0 Vp-p,
RF Modulated; VHF channel 2 or 3,
AUDIO IN (PHONO); more than-10 dBV,
MICROPHONE; -70 dBV
AUDIO OUT (PHONO); -8 dBV,
1 track (Normal-mono only), 2 channels (Hi-Fi sound-stereo)
Colour; more than 240 lines (SP)
Video; more than 43 dB (SP)
Audio; more than 90 dB (Hi-Fi audio track)
20 Hz-20 kHz (Hi-Fi audio track)
0.005% Wrms/Hi-Fi
5°C-40“C
35%-80%
5.4 kg
430(W)x96(H)x356(D) mm
1 pc. DIN-DIN Coaxial Cable
1 pc. Remote Controller
2 pcs. “R6" size batteries
1 pc. Stereo type Phono Cable
1 pc, AC Mains Lead
1 pc. Programming Sheet
75 ohm
75 ohm
75 ohm, terminated
more than 47 kohm
less than 1 kohm
Weight and dimensions shown are approximate.
Specifications are subject to change without notice.
