VCR Plus+ Setup
VCR Plus+ programming allows you to set most items of a timer recording by simply entering a special code (PlusCode) found in
TV GUIDE magazine as well as the TV listings in selected newspapers. In order for your VCR to do a VCR Plus+ recording, or a
timer recording of cable stations, some setup is required.
At first, choose your Connection Type.
(Then, follow the instructions under the diagram.)
[ Connection Type A
-► VCR -» TV>
From Cable r...............
Back of VCR
Cable Box' '
RF Coaxial
Cabla
R-AWX01.I. v«*0 iiv
CX/r^
nn TATk
RF Coaxial Cabla
(auppllad)
Back of TV...
Or,
i Cabte/'i|
: AfTtenr№l
Back of TV
Back of VCR
If your system connection iooks like one of
the diagrams above, do the following.
1. Complete “Cable Box Setup” at right.
2. Skip page 25 and go directly to page 26 for
VCR Plus+ Programming.
Connection Type B
From Antenna
or Cable
Back of VCR
Back of TV
Cable/ Ü
Antenna! i
RF Coaxial Cablo ^
(supplied)
Or,
Back of VCR
B.AUOOl-L VWCO 3rr
^
Back of TV
This connection allows
viewing (not recording)
of scrambled channels.
RF Coaxial Cable
(supplied)
Cable Box! ^una
If your system connection looks like one of
the diagrams above, do the following.
1. Skip “Cable Box Setup” at right and turn
to page 25.
2. Complete “VCR Plus+ Channel Setup”
on page 25.
3. Turn to page 26 for VCR Plus-i- Programming.
24
Cable Box Setup
For Connection Type A (see left) only
o Push MENU to
display the menu.
.................. MENU ................
SET UP VCR
SET CLOCK
SET UP CHANNEL
IDlOMA/LANGUE:ENGLISH
SELECT
SET
aci
Push AV to
select “SET UP
CHANNEL,” and
then push ► to display the
“SET UP CHANNEL” screen.
A T KEY
► KEY
MENU KEY
Push AV to
select “CABLE/
DSS BOX SET UP,”
and then push ►
to display the
“SELECT HOOKUP”
screen.
--- SET UP CHANNEL ---
ANTENNA SYSTEM : CATV
AUTO SET
VCR PIUS+ CH SET UP
SELECT:A ▼ KEY
SET :► KEY
END :MENU KEY
JD.
Push AV to
select your
hookuD, and then
push to set.
SELECT HOOKUP
CABLE/DSS BOXr-VCR^TV
VCF>CABLE/OSS BOX^TV
VCR>-TV
SELECT
SET
END
A T KEY
► KEY
MENU KEY
If you selected CABLE/DSS
BOX^VCR^TV, continue with step 5.
If not, push MENU three times and turn to page 25.
SELECT HOOKUP
CABLE/DSS BOX*-VCR^TV
CABLE/DSS BOX OUTPUT CH
SELECT
SET
END
A T KEY
► KEY
MENU KEY
Push AV to
select your cable
box or DSS
receiver output
channel number,
and then push ►
to enter.
If necessary, refer to your cable box manual.
If you are using Audio/Video jack connections to your cable
box, select and set “VIDEO OUT” as the output channel.
Push MENU twice to end the
Q setup and return to the
^ normal screen.
Go directly to “VCR Plus+ Programming”
on page 26.
