Location of Controls

Remote Control Buttons

VCR

See pages 28, 29.

VCR/TV
See pages 12,17.

PLAY

See pages 15, 21.
SELECT UP

See pages 12-14,18-20, 24-26

MENU
See pages 12-14, 20, 24, 25, 30.

NUMBERED KEYS

See pages 13,16, 21,26, 28.

INDEX
See page 21.

SPEED
See pages 16,26.

FAST FORWARD/SEARCH

See pages 15,21.

SET

See pages 12-14,18-20, 24-26, 30.

See pages 15.16,19, 21.

SELECT DOWN

See pages 12-14, 18-20, 24-26, 30.

COUNTER RESET
See page 20.

RECORD/TIME

See page 16.

SLOW

ADD/DELETE

See pages 13,19, 25, 26.

CHANNEL UP/DOWN

(TRACKING UP/DOWN)

See pages 12,13,15-17.

VOLUME UP/DOWN

See page 29.

ZERO SEARCH/

1 MINUTE SKIP

See page 20.

Front View of the VCR

POWER

See pages

12, 18, 19, 26.

CHANNEL UP/DOWN

TRACKING/V-LOCK

See pages 12,15-17.

VCR/TV

Selector
See pages

12.17, 27.

VIDEO Input

Connector
See page 27.

Cassette Compartment
See pages 15,16, 27.

AUDIO Input

Connector (L/R)

See page 27.

STOP/EJECT

See pages

15,16,19,21,27, 30.

FAST FORWARD/

SEARCH
See pages 15,19, 21.

RECORD/TIME

See pages 16,19, 27.

PLAY

See pages 15, 19, 21,27.

Multi Function Display
See pages 11,15-19, 26.

REWIND/SEARCH
See pages 15,19, 21.
