Multi Function Display

VCR Indicator

Lights when the VCR/TV

selector is set to VCR.

Power Indicator

Lights when power is on.

Hi-Fi Indicator

Lights when Hi-Fi audio is
monitored or played back.

Timer Indicator

Lights when the VCR is set for a

Timer Recording, or when a length

is set for a normal recording.
Flashes when a Timer Recording is
set, but a tape has not been
inserted into the VCR.

Clock/Status/Channel/Speed Display

Displays the current time.
Briefly displays VCR status when a function button is pushed.
Briefly displays the channel number, or “L1" or “L2” when a

channel or line input is selected.

Briefly displays the recording speed when SPEED is pushed.

Rear View of the VCR
