Design
• Aluminium housing with integrated
NiMH battery and with optional
radio modem.
Battery GEB111
• Type
Nickel metal hydride
(NiMH)
• Capacitance 1.8Ah
Power supply
The voltage when using an
external cable must be within the
range 11.5V to 14V (DC)
Current consumption
• 12/6V=
• 0.4 Amax
Environment
• Splashproof and dustproof
(IP53 in accordance with IEC 529)
Technical data
Temperature
Operation:
-20°C to +50°C
(-4°F to +122°F)
Storage: -40°C to +70°C
(-40°F to +158°F)
Dimensions
• 160 mm x 135 mm x 50 mm
Weight
• RCS1100 including modem 770g
• Battery GEB111
200g
• Reflector pole adapter 180g
Interface
• Conformable with RS232
• TxD, RxD, GND
• No hardware handshake
Baud rate
• 2400/4800/9600/19200/34800 bps
• Serial, asynchronous
Data format
• 7/8 data bits
• 1/2 stop bits
• Parity none/even/odd
Keyboard and display
Plugs
• One five-pole Lemo-0 plug for
external battery connection and
data transfer
Alphanumeric
characters
Maximum 256
Character set
Expandet ASCII
set as standard.
An optional
character set can
be loaded in
addition
Type of display LCD
Size of display
8 rows of 32
characters
Graphics
capability
Yes,
64 x 256 pixels
