Leica Geosystems RCS1100 Series - Manual (Page 23)

23
RCS1100-1.2.0en Operation
6
7
8
15
Activates the LAST
function.
Last point stored
If the LOCK mode is lost, this
function can be used to turn the
TPS1100 back to the last point
stored. When the movement is
complete, the TPS1100 automatically
starts to search for the prism.
Switches on/off the
RCS mode.
For using the remote control the
RCS mode must be switched on.
Switching the RCS mode
Lock interruption / Lock go
Activates the lock
interruption/relock.
This function serves to interrupt the
LOCK mode and later to reinstate it,
e.g. if the prism is placed on the
ground during stakeout or if the
TPS1100 is also to be targeted on a
second prism.
If this function is called up in
the RCS-mode the Joystick
dialog is automatically started. The
ATR remains active, i.e. if the
reflector reappears in the field of
view it is immediately relocked.
Activate/Deactivate Work Area (WORK+/WORK-)
Activates the function
activate/deactivate
working area.
If the instrument is in RCS mode and
the determined working area is
activated then the entire working
area is scanned for the reflector if
the target was not found by the
standard search method at the
current position of the telescope.
If the working area is deactivated
only the standard search methods at
the current position of the telescope
are performed.
The instrument follows the reflector
even if the reflector is outside the
Working Area.
If the target is lost outside
the Working Area a local
search will be started. If the reflector
was not found the predefined
Working Area is scanned.
On instruments with the optional
PowerSearch, the working area can
be used to limit PowerSearch to a
certain area and when activated,
PowerSearch only scans within the
defined limits.
