12 Preparation, Setting up RCS1100-1.2.0en
After all connections and settings
have been inspected, the RCS1100
can be switched on. This
automatically brings the TPS1100
into the RCS mode. After a few
seconds, the display of the TPS1100
appears on the RCS1100.
Switching on Trouble-shooting
Error Cause / remedy
No data transfer when
starting up (short
distance between
TCPS26 and RCS1100)
Case 1 - Green LED on TCPS26 does not shine:
Inspect battery charge, and cables for TCPS26
Case 2 - Message "No signal" on RCS1100:
Inspect battery charge in RCS1100
or possible link numbers for RCS1100 and
TCPS26 are not the same.
Case 3 - Green LED shines and message appears
on RCS1100: Set interface paarmeters correctly on
TPS and TCPS26.
Data transfer possible,
but transmission fault
Case 1 - Red LED on TCPS26 flashes: Inspect
interface parameters.
Case 2 - Red LED on TCPS26 does not flash:
Connecting cable is defective
Data transfer is very
slow
Disturbance from other transmitters in the 2.4 Ghz
frequency band: Change link number in RSC1100
and TCPS26.
Interruption during data
transfer
Message "No signal" on RCS1100:Operation is at
the limit of the range, or there is no visual
communication between RCS1100 and TCPS26.
Establish visual communication, reduce distance,
use antenna extension.
