Leica Geosystems RCS1100 Series - Manual (Page 19)

19
RCS1100-1.2.0en Operation
6
7
8
15
Activates the
function Definition
of a Working Area.
RCS Searching Window
Hz Search extent of search window
in Hz-direction
V Search extent of search window
in V-direction
To confirm the displayed
values and leave the dialog.
Returns all values to default
values.
With this function the dimensions of
the RCS Searching Window can be
defined. If an automatic reflector
search is started by pressing ALL or
DIST in RCS mode, a search window
with the predetermined dimensions
is scanned at the current position of
the telescope.
/ / Activates the
function RCS
Searching window.
...\ RCS Searching Window
Define size of searching
window
Hz Search: 40 g
V Search : 20 g
CONT DEFLT
MC
QUIT
Definition of a Working Area (WORKA)
With this function a Working Area
can be defined in which the
instrument automatically searches
for the reflector when working in
RCS mode.
Hz left left boundary of working
area
Hz right right boundary of
working area
V upper upper boundary of
working area
V lower lower boundary of
working area
QUIT
...\ Def. Working Area
current
Hz left : 171 g
Hz right : 243 g
V upper : 90 g
V lower : 114 g
CONT DEF SHOW
MC
