28 Operation RCS1100-1.2.0en
5
Modem internal / external
It can be ascertained whether the
radio modem being used is internal
or external.
If an external radio modem is used,
the interface parameters must be set
correctly.
This change will only take effect after
switching on/off the RCS1100.
Local functions, continued
RCS\ Modem Selection
Radio Modem: internal
CONT
MC
If the baud rate of the RCS1100
differs from that of the TCPS26, keep
repeating step 4 above until they
agree, when the interface
parameters of the RCS1100 will be
matched automatically.
If two external TCPS radio
modems are used, these
must be set in turn to the same link
number.
RCS\ Radio modem
Select link number for modem
and TCPS26 connected.
Link number: 0
CONT
MC
5. Call up the function "Radio/
ConfigureTCPS26".
6. Select a link number between 0
and 15.
7. Press the key. The link
number is now set correctly in the
internal radio module and in the
TCPS26.
