EDXtreme User Instructions 43
There are three soft keys on the first display and four on the second display. The soft
key functions are described below:
Units Changes the displayed unit of measure. Each press advances the display
through this sequence; lbf, kgf, N, custom 1, custom 2.
Print Outputs serial data to peripheral devices attached to COM 1.
Clr.All Clears the peaks on all EDXs currently in communication with the remote.
Clear Clears the current peak value of the active EDX.
UZ.All Resets all EDXs to calibration zero reference point.
Z.All Zeros all EDXs currently in communication with the remote.
Setup Accesses the Setup menu shown in Figure 6.1 .
Config Accesses the Config menu shown in Figure 6.3 .
6.2 Communicator Setup Menu
The Communicator Setup menu can be accessed using the softkey or the Remote
Setup hardkey. Press the right Arrow key to access the Setup menu softkey.
Figure 6.1 Communicator Setup Menu
Setup
PtFmt Misc About Test
Batt Disp Keys Comm Ntwrk
Cell Com 1
Press KEY to test.
Press ESC key to
exit
Run display test
View Battery
Voltage and temp.
About
Display Device
info, SN, FW and
PN
Flash Contr BLite
Inten Mode
Selected Backlight
ON, OFF or Timer
operation
If Timer enabled
then: Enter time in
Seconds
Choose Motion
Reset Timer: YES
or NO
Choose backlight
intensity: 1- 10
Adjust Contrast
Up or DOWN
Enable Key Blink/:
YES or NO
Choose default
print format: 1 - 5
Run network test
Continued on
the next page
Date/Time
(Enabled,
Disabled)
