CanogaOS Configuration Guide
9-7
9.4.1 Topology
eth-0-9
Switch 1
(M)
Switch 2
(E)
Switch 3
(A-E)
Switch 4
(M)
eth-0-9
eth-0-13
eth-0-13
eth-0-20
eth-0-20
eth-0-13
eth-0-13
eth-0-9
eth-0-9
Ring 1(Primary)
Ring 2(Sub)
Figure 9-2: Single-Domain Intersecting-Ring Topology
9.4.2 Configurations
Switch 1
Create VLANs for transferring ERPS control packets
DUT# configure terminal
Enter the configure mode.
DUT(config) # vlan database
Enter VLAN database mode.
DUT(config-vlan) # vlan 11,12
Creat vlan 11, 12.
DUT(config-vlan) # exit
Exit the vlan mode and enter the Configure mode.
Configure interface eth-0-9
DUT(config) # interface eth-0-9
Enter the Interface mode.
DUT(config-if)#switchport mode trunk
Set the switching characteristics of this interface to
trunk mode.
DUT(config-if)#switchport trunk allowed vlan add
11,12
Enable VLAN 11, 12 on this port.
DUT(config-vlan) # exit
Exit the interface mode and enter the Configure mode.
Configure interface eth-0-13
