CanogaOS Configuration Guide
17-6
DUT# configure terminal Enter the Configure mode
DUT (config)# router ospf 200 Configure the Routing process and specify the Process ID
(200). The Process ID should be a unique positive integer
identifying the routing process.
DUT (config-router)# network 10.10.10.0/24 area 0 Define the interface (10.10.10.0/24) on which OSPF runs
and associate the area ID (0) with the interface.
DUT (config-router)# network 10.10.11.0/24 area 1 Define the interface (10.10.11.0/24) on which OSPF
runsand associate the area ID (1) with the interface.
DUT(config-router)# area 1 stub no-summary (Optional) Define an area as a stub area. The no-summary
keyword prevents an ABR from sending summary link
advertisements into the stub area.
Validation Commands
show ip ospf, show ip ospf interface
17.7 Redistributing Routes into OSPF
In this example the configuration causes BGP routes to be imported into the OSPF
routing table and advertised as Type 5 External LSAs into Area 0.
Topology
Figure 17-4: OSPF Routes Redistributing
Configurations
R1
