CanogaOS Configuration Guide
30-12
Command Description
DUT1(config-router)# transport-address 11.11.11.11 Configure Transport Address in LDP.
DUT1(config-router)#exit Exit the router-ldp mode.
DUT1(config)#ip vrf vpn2 Configure a VPN routing and forwarding(VRF)
routing table
DUT1(config-vrf)#rd 1:100 Assign a route distinguisher (RD) for the VRF.
DUT1(config-vrf)#route-target both 1:100 Add a list of import and export route-target extended
communities to the VRF.
DUT1(config-vrf)#exit Exit VPN routing and forwarding(VRF) routing
table.
DUT1(config)#interface eth-0-1 Enter the Interface mode.
• eth-0-1—Specify the interface
DUT1(config-if)# no switchport Configure the port to layer 3 port.
DUT1(config-if)#ip vrf forwarding vpn2 Associate a VPN routing and
forwarding(VRF)instance with an Layer3 interface.
DUT1(config-if)#ip address 5.5.5.1/24 Create IP address on the port.
DUT1(config-if)#exit Exit the Interface mode.
DUT1(config)#router rip Enter the router-rip mode
DUT1(config-router)#network 4.4.4.0/24 Associate networks with the RIP process.
DUT1(config-router)#network 11.11.11.11/32 Associate networks with the RIP process.
DUT1(config-router)#exit Exit the router-rip mode.
DUT1(config)#mpls enable-all-interfaces Enable label-switching on all interfaces.
DUT1(config)# router bgp 1 Configure a BGP routing process.
DUT1(config-router)# bgp router-id 11.11.11.11 Configure the router identifier.
DUT1(config-router)# neighbor 10.10.10.10
remote-as 1 Configure an internal or external BGP (iBGP or
eBGP) TCP session with another router.
DUT1(config-router)# neighbor 10.10.10.10
update-source loopback0 Allow internal BGP sessions to use any operational
interface for TCP connections.
DUT1(config-router)# address-family ipv4 Enter the IPv4 address-family command mode.
DUT1(config-router-af)# neighbor 10.10.10.10
activate Enable the exchange of the specified AF routes with
a neighboring router.
DUT1(config-router-af)# neighbor 10.10.10.10
send-community both Specify that a community attribute should be sent to
a BGP neighbor.
DUT1(config-router-af)# redistribute connected Redistribute connected routes in the VRF.
DUT1(config-router-af)# redistribute static Redistribute static routes in the VRF.
DUT1(config-router-af)# exit-address-family Exit the address family mode.
DUT1(config-router)# address-family vpnv4 unicast Enter the vpnv4 address-family command mode.
DUT1(config-router-af)# neighbor 10.10.10.10 Enable the exchange of the specified AF routes with
