VLAN Multiplexing 9145EMP NID Software User’s Manual
VLAN Multiplexing Configuration
181
12.2 VLAN Multiplexing Configuration
Use the following steps to navigate to the VLAN Multiplexing Records List. The Record List is the
main entry point to VLAN Multiplexing configuration and Statistics monitoring. It displays all VLAN
Multiplexing records in the system. Each VLAN Multiplexing record is uniquely identified by the
S-VLAN ID.
1. On the Main Menu (Figure 12-2), type 12 and press Enter. The VLAN Multiplexing
Record List (Figure 12-3) opens.
Figure 12-2 Main Menu
Canoga Perkins Corp. Ethernet Network Interface Device 02-JAN-2010
Model 9145EMP-761-0-0 V07.11 F7 Canoga 9145EMP 32 device 05:15:27
----------------------------------MAIN MENU------------------------------------
1) System Configuration
2) Diagnostics
3) Port Information
4) System Alarms
5) System Log
6) Utilities
7) Software Upgrade
8) Manage Logged In Users
9) Link OAM
10) CoS Configuration
11) Service OAM
12) VLAN Multiplexing
13) Logout
Select [1-13]:
