CANOGA PERKINS 9145EMP NID Software Version 3.1 - Manual (Page 132)

9145EMP NID Software User’s Manual CoS Configuration
CoS Queues Configuration
120
Figure 10-16 ED Drop Profile Match Criteria (User Port)
Canoga Perkins Corp. Ethernet Network Interface Device 01-JAN-2009
Model 9145EMP-761-0-0 V11.10 F11 Canoga 9145EMP 32 device 00:22:43
---------------------USER PORT MATCH CRITERIA FOR PROFILE 1A--------------------
DSCP Match DSCP Match DSCP Match DSCP Match DSCP Match DSCP Match DSCP Match
0 X 10 X 20 X 30 X 40 X 50 X 60 X
1 X 11 X 21 X 31 X 41 X 51 X 61 X
2 X 12 X 22 X 32 X 42 X 52 X 62 X
3 X 13 X 23 X 33 X 43 X 53 X 63 X
4 X 14 X 24 X 34 X 44 X 54 X
5 X 15 X 25 X 35 X 45 X 55 X
6 X 16 X 26 X 36 X 46 X 56 X
7 X 17 X 27 X 37 X 47 X 57 X
8 X 18 X 28 X 38 X 48 X 58 X
9 X 19 X 29 X 39 X 49 X 59 X
PCP Match PCP Match PCP Match
0 X 3 X 6 X
1 X 4 X 7 X
2 X 5 X
Select DSCP or a Range x-y [0-63]:
Enter CTRL-D to toggle DSCP/PCP, CTRL-T to toggle profile A/B
------------------------------------Messages-----------------------------------
