5. For 802.1ag, to view the VLAN list for that MIP, type 2 and press Enter. The MIP’s Main-
tenance Association List opens. If you are configuring a Y.1731 MIP, the VLAN number is
displayed on the screen.
6. If you are configuring an 802.1ag MIP, type A to accept the settings and press Enter.
Press Esc to return to the Maintenance Intermediate Point Attributes screen.
If you are configuring a Y.1731 MIP, go to step 7.
Figure 11-35 Maintenance Intermediate Point Attributes screen (802.1ag)
7. For Y.1731, to change the AIS Transmit interval, type 2 and press Enter. Select 1 sec or 1
min and press Enter.
8. To change the AIS priority bits, type 3 and press Enter. Type a number from 0 to 7 and
press Enter.
9. Type A to accept the settings and press Enter. Press Esc to return to the Maintenance
Intermediate Point Attributes screen.
Canoga Perkins Corp. Ethernet Network Interface Device 02-JAN-2009
Model 9145EMP-761-0-0 V07.11 F7 Canoga 9145EMP 32 device 05:15:27
------------------MAINTENANCE INTERMEDIATE POINT ATTRIBUTES---------------------
MIP ID: 44 Type: 802.1ag Level: 7
MD ID: 8 Port: USR2 MAC: 00:40:2A:01:EE:23
1) Admin status: Enabled
2) To see VLAN list.
Select [1-2] for attributes:
------------------------------------Messages-----------------------------------
