9145EMP NID Software User’s Manual Service OAM
Maintenance End Points
158
Figure 11-25 Linktrace Request screen
Figure 11-26 Linktrace Monitoring screen
Canoga Perkins Corp. Ethernet Network Interface Device 02-JAN-2009
Model 9145EMP-761-0-0 V07.11 F7 Canoga 9145EMP 32 device 05:15:27
------------------------------LINKTRACE REQUEST--------------------------------
MEP ID: 1
1) Destination: MAC Address: 00:00:00:00:00:00
2) FDB only flag: No
3) Initial TTL value: 64
No results for this request yet.
Select [1-3] for attributes, (S) to send:
------------------------------------Messages-----------------------------------
Canoga Perkins Corp. Ethernet Network Interface Device 02-JAN-2009
Model 9145EMP-761-0-0 V07.11 F7 Canoga 9145-MP 32 device 05:15:27
------------------------------LINKTRACE MONITORING ----------------------------
MEP ID: 1
1) Destination: MEP ID : 2
2) FDB only flag: No
3) Initial TTL value: 64
Linktrace number of replies: 1
Destination reached: Yes
Number of hps to destination: 1
Select [1-3] for attributes, (S) to send:
Select (S) to see results, (R) for a new request:
------------------------------------Messages-----------------------------------
