802.3AH OAM 9145E NID Software User’s Manual
OAM Statistics
85
Figure 9-3 The OAM Peer Information Screen
Figure 9-4 OAM Statistics screen
Canoga Perkins Corp. Ethernet Network Interface Device 24-APR-2009
Model 9145E-404-8-0 V01.00 F506 09:52:48
-----------------------------------OAM PEER INFORMATION------------------------
User Port Peer Network Port Peer
OAM Peer Status Inactive Inactive
OAM Peer MAC Address Unavailable Unavailable
OAM Peer Vendor OUI Unavailable Unavailable
OAM Peer Vendor Info (Hex) Unavailable Unavailable
OAM Peer Mode Unknown Unknown
OAM Peer Max PDU Size Unavailable Unavailable
OAM Peer Config Revision Unavailable Unavailable
OAM Peer Functions Supported Unavailable Unavailable
Press ESC to return to previous screen
------------------------------------Messages-----------------------------------
Canoga Perkins Corp. Ethernet Network Interface Device 24-APR-2009
Model 9145E-404-8-0 V01.00 F506 09:53:38
----------------------------OAM STATISTICS (CURRENT)---------------------------
User Port User Port Net Port Net Port
Sent Rcvd Sent Rcvd
--------- --------- --------- ---------
Information OAMPDUs 0 0 0 0
Unique Event Notifications 0 0 0 0
Duplicate Event Notifications 0 0 0 0
Loopback Control 0 0 0 0
Variable Requests N/A 0 N/A 0
Variable Responses N/A 0 N/A 0
Organization Specific OAMPDUs N/A 0 N/A 0
Unsupported Opcodes N/A 0 N/A 0
Total OAMPDUs 0 0 0 0
CTRL-T to view raw counters, CTRL-R to reset OAM counters,
TAB to view Link Event Statistics, ESC to return
------------------------------------Messages-----------------------------------
