IP/SNMP Agent Configuration
17
Figure 3-9 V1-Trap or V2c-Trap Notification Type Parameter
• If V3-Trap was selected (Figure 3-11):
a. Use the Space Bar to select the Security Name and press Enter.
b. Use the Space Bar to select the Security Level (No Auth/No Priv, Auth/No Priv, or Auth/Priv)
and press Enter.
c. Press Esc to return to the Trap Table menu (Figure 3-7).
• If V3-Inform was selected (Figure 3-13):
a. Type in the Security Name and press Enter.
b. Type in the SNMP Engine ID and press Enter.
c. Cycle through the Authentication Protocol setting (MD5, SHA, or None) using the Space
Bar. Press Enter to accept the setting.
d. Type in the Authentication Password and press Enter. Type in the password again and
press Enter. The Authentication Key will automatically be entered (It can be modified to
match the SNMP manager's key if needed.).
e. Cycle through the Privacy Protocol settings (DES or None) using the Space Bar and press
Enter to accept the setting.
f. Type in the Privacy Password, if required, and press Enter, then type in the password again
and press Enter. The Privacy Key will automatically be entered (It can be modified to match
the SNMP manager's key if needed.).
g. Cycle through the Security Levels (No Auth/No Priv, Auth/No Priv, or Auth/Priv) using the
Space Bar and press Enter to accept the setting.
Canoga Perkins Corp. Ethernet Network Interface Device 21-APR-2009
Model 9145E-404-8-0 V01.00 F506 09:06:01
----------------------------------EDIT TRAP/NOTIFICATION TYPE------------------
IP Address : 172.002.145.003
Trap/Notification Port : 162
Notification Type : V1-Trap
1. Community Name : Stepford
Select [1]:
------------------------------------Messages-----------------------------------
