Port Information 9145E NID Software User’s Manual
Port Configuration
49
Figure 5-3 Port Configuration Menu
Figure 5-4 Hardware Information Menu
Canoga Perkins Corp. Ethernet Network Interface Device 23-APR-2009
Model 9145E-404-8-0 V01.00 F506 11:04:33
-------------------------------PORT CONFIGURATION------------------------------
1) Hardware Information
2) Functional Configuration
3) VLAN Configuration
4) Port Filters
5) Port Based VLAN Control
Select [1-5]:
------------------------------------Messages-----------------------------------
Canoga Perkins Corp. Ethernet Network Interface Device 23-APR-2009
Model 9145E-404-8-0 V01.00 F506 11:05:30
-----------------------------------HARDWARE INFORMATION------------------------
NID Model Number 9145E-404-8-0
NID Hardware Rev. A1
NID Serial Number 20080814163
SFP Information User Port Network Port
Model Number SFP Not Present SFP1-0045
Wavelength N/A 850nm MM
Connector Type N/A Duplex LC
Data Rate N/A 1000Mbps
Maximum Line Length N/A N/A
Maximum Loss Budget N/A 7.5dB
Power Supply A 48V DC
Power Supply B 48V DC
Press ESC to return to previous screen
------------------------------------Messages-----------------------------------
