GVRP INFORMATION
PORT/LAG MODE JOIN TIMER LEAVE TIMER LEAVEALL TIMER
SP 1 Disable 20 60 1000
SP 2 Disable 20 60 1000
SP 3 Disable 20 60 1000
SP 4 Disable 20 60 1000
1. GVRP Mode : disabled
2. View/Change Interface :
3. Main Menu
Figure 25. GVRP Information Screen
4.7 Port Information
The Port Information screen shows the current conditions for all ports in the 9161 with options to
view parameters and statistics for specific ports. See Figure 26 and Table 8. To access the Port
Information screen, follow these steps:
1. From the Main menu, type 3, "Port Information," and press .
2. At the Port Information screen menu, type a number to view an option, then type the port number,
and press . The In formation or Statistics screen appears for port 10G x; see Figures 27
and 28.
3. To return to the Main Menu, type 3.
PORT INFORMATION
XFP1-2263 Empty Slot
_________________________________
| | |
| Tx Rx | Tx Rx |
| o G | o o |
| | |
| NET | NET |
| o | o |
|________________|________________|
10G-1 10G-2
1. Port Information :
2. Port Statistics :
3. Main Menu
Figure 26. Port Information Report and Menu
Table 8. Port Information Menu Definitions
Parameter Description
1. Port Information View the information and set values for parameters for a selected port
2. Port Statistics View the statistics for a selected port
3. Main Menu Return to Main Menu
9161 Network Interface Device 4-16
