GLOBAL SPANNING TREE PARAMETERS
1. Admin Mode : disabled
2. Version : 802.1s
3. Configuration Name : 00-40-2A-12-34-00
4. Configuration Revision : 0
5. Priority : 32768
6. Hello Time (sec) : 2
7. Forward Delay (sec) : 15
8. Max Age (sec) : 20
9. View/Change Interface :
10. Main Menu
Figure 17. Global Spanning Tree Parameters Menu
Table 7. Global Spanning Tree Parameters Menu Options
Menu Item Description
1. Admin Mode Enable or disable administrator mode
2. Version Shows which IEEE specification this meets
3. Configuration Name Name for configuration, typically MAC address, up to 32 characters
4. Configuration Revision Set a revision level between 1 and 65535
5. Priority Set the relative precedence within the STP control structure for the
9161, from 1 (highest) to 65534 (lowest). The highest priority sets
the root bridge, the bridge that controls the spanning tree. If two or
more bridges share the same priority, the lowest MAC address
defines the highest priority.
6. Hello Time (sec) Set how often the 9161 sends BPDUs if this 9161 is the Spanning
Tree root.
7. Forward Delay (sec) Set the time between port state transitions from Learning to Forward
if this bridge is the Spanning Tree root.
8. Max Age (sec) Set the Timeout value, how fast the 9161 deletes addresses from the
forwarding database.
9. View/Change Interface Set a specific STP port for viewing
10. Main Menu Return to the Main Menu
4.6.2 Multiple Spanning Tree Parameters
Use the Multiple Spanning Tree (MST) Instance Configuration screen to view and set up instances of
grouped or associated VLANs in independent STPs. See Figure 18. To access the MST Instance
Configuration screen, follow these steps:
1. From the Switch Configuration menu, type 2, "Multiple Spanning Tree Parameters," and press
.
2. At the MST Instance Configuration screen, type the number for an item and press , then
follow the prompts.
9161 Network Interface Device 4-12
