IP SETTINGS
Local MAC Address : 00 00 00 06 01 00
1. Local IP Address : 172.16.3.34
2. Subnet Mask : 255.255.0.0
3. Gateway IP Address : 172.16.1.1
4. Enable BOOTP Mode : no
5. Management VLAN Id : 1
6. Telnet Host Verification : disabled
7. Static ARP Table
8. Dynamic ARP Table
9. Main Menu
Figure 8. IP Settings Screen
Table 4. IP Settings Definitions
Menu Item Description
Local MAC Address View the MAC address for this 9161
1 Local IP Address Set the IP address for this 9161
2 Subnet Mask Set the subnet mask
3 Gateway IP Address Set the IP address for the gateway
4 Enable BOOTP Mode Enable or disable BOOTP requests
5 Management VLAN Id Set the number for the VLAN
6 Telnet Host Verification Enable or disable checking whether host is listed in host table;
default is disabled, which allows access to all hosts
7 Static ARP Table Set or change specific IP and MAC addresses
8 Dynamic ARP Table View current IP and MAC addresses
9 Main Menu Returns directly to the Main Menu
Use the Static ARP Table to set specific IP and MAC addresses for up to 10 ports. See Figure 9.
STATIC ARP TABLE
IP Address MAC ADDRESS
1. 172.16.2.7 00-90-37-56-6C-34
2. 172.16.3.23 00-7C-25-33-57-9C
Figure 9. Static ARP Table Screen
To use view, set, or remove an address, follow these steps:
1. From the IP Settings screen, type 6 , "Static ARP Table," and press .
2. At the prompt, type 1 to add an entry or 2 to remove an entry, and follow the prompts.
9161 Network Interface Device 4-6
