Page 29: 4 alarm output configuration

EdgeAccess Universal Chassis System
L351 10/100BASE Media Converter
4-10
TRAP CONFIGURATION
1) Master Trap Control
Disabled
2) Extension Port Link Traps
Enabled
3) Remote Fault Received Traps
Enabled
4) Link Loss Forwarding Traps
Enabled
5) Link Loss Echo Traps
Enabled
6) Remote User Port Link Traps
Enabled
7) Local User Port Link Traps
Enabled
8) Configuration Traps
Enabled
9) Power/Fan/Temperature Traps
Enabled
10) Cold Start Traps
Enabled
11) Side Band Mgmt Channel Traps
Enabled
12) Alarm Input Traps
Enabled
13) Diagnostics Traps
Enabled
14) Authentication Traps
Disabled
Figure 21. Trap Configuration Screen
4.5.4 Alarm Output Configuration
Use the Alarm Output Configuration screen to set any or all alarms to Major, Minor, or Off. See
Figure 22 and Table 5. To configure alarms, follow these steps:
1. From the Main Menu type
3
, "Alarm Output Configuration," and press
Output Configuration screen appears.
2. Type the number for the alarm you want to set and press
3. Press
ALARM OUTPUT CONFIGURATION
1) Factory Defaults
2) Link Down Alarm
Off
3) RMTF Alarm
Off
4) LLF Alarm
Off
5) Configuration Alarm
Off
6) Power/Fan/Temperature Alarm
Minor
7) SBMC Loss Alarm
Off
8) Power-On Self Test Alarm
Off
Figure 22. Alarm Output Configuration Screen
Table 5. Alarm Output Definitions
Alarm
Description
2) Link Down
Loss of Signal (electrical)/Composite Loss of Signal (optical); one
or both received signals fail; default is Off
3) RMTF
Remote fault received; default is Off
