EdgeAccess Universal Chassis System
L351 10/100BASE Media Converter 4-7
4.5.2 Functional Configuration Screen
The Functional Configuration report and menu provide information about the switches set in
hardware (for details, see Chapters 2 and 3), with options to set software control. You can only view
the options for the Remote module, but you can set options for the Local L351 to work with the
Remote module. To access the Functional Configuration screen, see Figure 15 and Table 4 and
follow these steps:
1. From the Main Menu, type
1
, "System Configuration," and press . The System
Configuration menu appears.
2. From the System Configuration menu type
2
, "Functional Configuration," and press .
3. At the Functional Configuration screen, type the number for an item and press , then
press to cycle through the options and press to select an option for the local
L351.
4. To return to the System Configuration menu, press .
FUNCTIONAL CONFIGURATION
Local
Remote N525
Chassis/Slot 4/3B 2/5
User Port Speed/Duplex 100M/Half 100M/Half
Switch Settings:
User Port Speed 10M 10M
User Port Autonegotiation Enabled Enabled
User Port Duplex Half Half
Side Band Mgmt Enabled Enabled
LLF Extension to User Disabled Disabled
LLF User to Extension Disabled Disabled
RMTF Disabled Disabled
1) Configuration Option Control Hardware Hardware
2) User Port Speed/Duplex Autonegotiate Autonegotiate
3) RMTF Enabled Enabled
4) Link Loss Fwd Disabled Disabled
5) Remote Configuration
Figure 15. Functional Configuration Screen
Table 4. Functional Configuration Option Definitions
Menu Item Description
1) Configuration
Option Control Set the L351 to follow settings in software and ignore SW2 and SW3 settings
2) User Port
Speed/Duplex Set the User Port to specific data rate and duplex options, to automatic rate
and duplexing, or disable it
3) RMTF Enable or disable RMTF if SBMC is enabled or RMTF/LLE if SBMC is
disabled
