Rev 9 Feb/2009
A-7
KMD 550/850 Appendix A
Icon Colors Description
Black on cyan Traffic sensor in standby mode being displayed.
Black on cyan Active traffic information being displayed.
Black on gray Traffic sensor in standby mode, not being displayed.
Black on yellow TIS service not available.
Black on gray Traffic sensor active, not being displayed.
Black on gray with red
slash Traffic sensor data invalid / not being displayed.
Brown on cyan EGPWS with warnings are enabled, being displayed.
Brown on cyan with
yellow “!” EGPWS with warnings are disabled, being displayed.
Black on gray EGPWS with warnings are enabled, not being
displayed.
Black on gray with
yellow “!” EGPWS with warnings are disabled, not being
displayed.
Black on gray with red
slash EGPWS data invalid / not being received.
Icon Description
0 min – 15 min Datalink lightning information received and displayed.
0 min – 15 min Datalink lightning information received but not displayed.
15 min – 30 min Datalink lightning information received and displayed but
data is more than 15 minutes old.
15 min – 30 min Datalink lightning information received but not displayed
and data is more than 15 minutes old.
> 30 min Datalink lightning is not being received.
Icon Description
Severe Weather Storm track information being received and displayed.
Severe Weather Storm track information being received but not displayed.
Severe Weather Storm track information not being received / data invalid.
