KMD 550/850 Appendix A
Rev 9 Feb/2009
A-3
Feature Conditions Icon / Colors Other Characteristics
TOPO on TOPO off
Airspace
Boundary Prohibited Yellow
and
black
dashed line with
black on white
label
Yellow
and
black
dashed line
with black on
white label
May be enabled or dis-
abled based on Map
Setup page (4) setting.
Highlighted when the
line is designated with
the joystick pointer. The
boundary label will be
“PHB”.
MOA/MATZ Solid
magenta
line with
black on white
label
Solid
blue line
with
black on white
label
May be enabled or dis-
abled based on Map
Setup page (4) setting.
Highlighted when the
line is designated with
the joystick pointer. The
boundary label will be
“MOA” or “MATZ” as
appropriate for the air-
space type.
Other SUA
(Radar
Area, Alert,
Caution,
Training,
Warning or
Unspecified/
Unknown) Solid
magenta
line with
black on white
label
Solid
blue line
with
black on white
label
May be enabled or dis-
abled based on Map
Setup page (4) setting.
Highlighted when the
line is designated with
the joystick pointer. The
boundary label will be
“ALT”, “CTN”, “DGR”,
“MOA”, “PHB”, “RES”,
“TNG”, “WNG”, “ADV”,
“CBA”, “TRA”, “TSA”, or
“UNK” as appropriate for
the airspace type.
Cities Black icon
with white
on black label
Not displayed May be enabled or dis-
abled based on Map
Setup page (2) setting.
The label will indicate
the city name.
Highlighted when the
icon is designated with
the joystick pointer.
Intersections
(INTs) Black icon
with white
on black label
White icon
with white
on black label
May be enabled or dis-
abled based on Map
Setup page (2) setting.
The label will indicate
the intersection identi-
fier. Highlighted when
the icon is designated
with the joystick pointer.
