Rev 9 Feb/2009 KMD 550/850 Pilot's Guide
FUNCTION SELECT KEYS
These keys are used to select available data sources (as indicated on
the key) for display on the LCD. When a function key is pressed, the
annunciator above it will illuminate to show that this function is presently
being displayed. Pressing the same Function Select Key multiple times
will sequence through the available pages associated with that function.
The following diagram shows the available pages under each function.
Note that not all pages will be available in all installations.
POWER KEYS
These five keys are used to manipulate the page being displayed. Their
present functionality can be indicated by the use of Soft Labels on the
left side of the key or Power Labels on the right side of the key.
POWER LABELS
When the Power Label is illuminated on the right side of the key, that
key’s function is dedicated to the function described by the label and that
function is active. The following is a list of the dedicated functions:
MODE- Pressing this key will sequence through all available modes
associated with the displayed page.
RNG
Δ-
Pressing this key will increase the range scale one level on
the displayed page. Range scales on other pages will not
be affected.
RNG
∇- Pressing this key will decrease the range scale one level on
the displayed page. Range scales on other pages will not
be affected.
VIEW- Pressing this key will sequence through the available views
associated with the displayed page.
General Information
WX TRFC TERR AUX MAP
Stormscope
EGPWS TAS/TCAS/TIS
External
NTSC Video
Setup Pages
* KMD 850 Only
Topo On
Map
WX Radar*
Topo Off
Map
Datalink Wx
Graphical
Products
Datalink Wx
Textual
Products
