Feature Conditions Icon / Colors Other
Characteristics
TOPO on TOPO off
Airports Soft or
unknown
runways Outline
black circle
with line repre-
senting primary
runway and
white on black
label
Outline cyan
circle with
cyan line repre-
senting primary
runway and white
on black label
May be enabled or
disabled based on
Map Setup page (2)
setting. When
enabled, the airport
label will identify the
ICAO code, city name
or airport name based
on the Map Setup
page (1) setting.
Highlighted when the
icon is designated with
the joystick pointer. If
the database does not
have runways for the
airport, then the icon
will not indicate a
runway (no line will be
shown).
Airport
Runways Primary,
hard surface Thick
black line
with white
on black label at
each end
Thick
white line
with white
on black label at
each end
Runways will be
depicted for airports
within 5 nm of the cur-
rent position when the
selected range is 10
nm or less and the dis-
play of airport icons is
enabled on Map Setup
page (2). Runway
ends will be labeled
with the proper runway
identifier if the
selected range is 1
nm. For selected
ranges 2.5 nm through
10 nm, the runways
will not be labeled.
Other hard
surface Thin
black line
with
white on black
label at each end
Thin white
line with
white on
black label at
each end
Primary,
soft surface Thick
green line
outlined in
black with white
on black label at
each end
Thick green
line outlined
in white
with white on
black label at
each end
Other soft
surface Thin
green line
outlined
in black with
white on black
label at each end
Thin green
line out-
lined in
white with white
on black label at
each end
Helipads Black on
white icon
with white on
black label
White on
black icon
with white on
black label
May be enabled or
disabled based on
Map Setup page (2)
setting. The label will
indicate the city name.
Highlighted when the
icon is designated with
the joystick pointer.
