FPD 500 FLAT PANEL DISPLAY SYSTEM
6.3 MAINTENANCE PAGE 3
The following is the definition of
the states for the page:
Parameter States
LAMP REPLACE/
PASS/FAIL
IP, GP,ETC. PASS/FAIL
6.4 MAINTENANCE PAGE 4
The following is the definition of
the states for the page:
Parameter States
PUSHBUTTON 0/1
NOTE: Remember, if you are
testing the buttons, that pressing
the R button will advance to the
next page, and pressing the N
button will exit the maintenance
mode.
Maintenance Mode Displays
6-3
Rev. 0
Jan/97
A
N
M
R
I
DIM
TEST
BRT
DU BEZEL STATUS PG 04
BRT PUSHBUTTON 0
DIM PUSHBUTTON 0
N PUSHBUTTON 0
M PUSHBUTTON 0
R PUSHBUTTON 0
I PUSHBUTTON 0
TEST PUSHBUTTON 0
Figure 6.4-1
Maintenance Page 4
N
M
R
I
DIM
TEST
BRT
DU STATUS PG 03
LAMP PASS
IP PASS
GP PASS
POWER SUPPLY PASS
DIMMER/LCD PASS
I/O #1 PASS
I/O #2 PASS
BEZEL PASS
Figure 6.3-1
Maintenance Page 3
