5.2.2 HSI SELF TEST
Press and hold the TEST button on the HSI to initiate the three phas-
es of self test. Release of the button will cause the previous display to
return, unless BIT test is in progress, in which case the test will com-
plete, then the display will return.
Phase 1 - A static display that imitates the electromechanical self test
for five seconds.
• No failure flags displayed
• Compass Card - 0° (north), digital heading “000”
• Source/Distance Display - INSX/3999; or DMEX/399.9 if available,
if not available, then blank
• Glideslope - Centered
• Selected Course - 90°
• Lateral Deviation - Centered
• TO/FROM - Both displayed
• Heading Bug - 180°
If ARC or MAP mode:
•Off Scale Symbols - Both heading bug and course pointer displayed
Phase 2 - All failure and warning flags flashing for five seconds.
• Source/Distance Display - Decluttered
• Selected Course - Decluttered
• Lateral Deviation - Decluttered
• TO/FROM - Decluttered
• Heading Bug - Decluttered
• Digital Heading/Lubber Mark - Decluttered
Phase 3 - Steady flags displayed while internal BIT test performed.
Same as Phase 2 except flags remain on steady
Operating Instructions
