*Connect the air filter
connector to the
carburetor.
3x8mm
Hex Screw
10017
Air Filter Cap
10016
Air Filter
Sponge
10017
Air Filter
Mount
10021
Air Filter
Connector
10020
Nylon Strap
(Small)
Apply filter oil to the
sponge before use.
Step1 Step2
30800
2X4mm
Screw
30800
2X7x0.5mm
Washer
30800
2mm
Tie-Rod
End
30800
2mm
Tie-Rod
End
30800
Adjust Mount
30800
2mm
Adjust Mount
94033
3x3mm
Set Screw
30800
Servo
Mount
30800
2X25mm
Hex Screw
94033
3x3mm
Set Screw
94033
3x3mm
Set Screw
30800
Throttle
Slider
94004
3x10mm
Hex Screw
30800
10300
Alum Stopper
30800
10300
Alum
Stopper
30800
30171
2X65mm
Rod
30800
2X65mm
Rod
30800
2X65mm
Rod
30800
10300
Throttle
Spring
30560
Antenna Pipe
94033
3x3mm
Set Screw
10300
Alum
Stopper
Snap On.
30800
10292
Throttle
Ball End
X2
2X4mm
Screw
X2
2X8mm
Screw
M2 Nut
X2
94033
M3x3
Set Screw
X3
X1
94004
3X10mm
Hex Screw
USING BREAK ADJUST NUT
Loose
Tighten
More Brake Less Brake
Tighten or loose the
adjuster nut will
change the brake.
ASSEMBLY OF THE THROTTLE LINKAGE
ASSEMBLY OF THE BRAKE LINKAGE INTO
BRAKE LEAVE
ASSEMBLY OF THE AIR FILTER
Step3
Step5 Step4
30800
2X8mm
Screw
10768
Servo Horn
30800
2mm
Nut
10769
Servo Horn
Adapter
* Put the antenna wire thought
the antenna pipe.
2X7x0.5mm
Washer
2X4mm
Screw
2X25mm
Screw
X1
Use the screw
provided with
your servo.
