OFNA Racing Ultra Comp2 User Manual
Page 21
38280
3X36mm
Turnbuckle
94004
3X12mm
Hex Screw
*Use the screw
provided with
your servo.
10114
5X12mm
Hex Screw
10711
Servo Horn
3737
6mm
Ball & Socket
37370
6mm
Ball & Socket
94004
3X12mm
Hex Screw
10711
Servo Horn
Adapter
X2
94004
3X12mm
Hex Screw
40104
4x12mm
Flat Head Hex Screw
X1
40104
4x12mm
Flat Head
Hex Screw
40199
Plastic Ball
End
40199
Plastic Ball
End
ASSEMBLY OF THE ENGINE ONTO CHASSIS
ASSEMBLY OF THE FRONT STEERING ROD
94042
M4 Nylon Nut
X4
94042
4mm
Nylon Nut
94036
5x5mm
Set Screw
30491
Muffler Stay
X1
94036
5x5mm
Set Screw
