MIDI Transfer
It is possible to transfer an individual Memory or all Memo-
ries from the MM 42 to another MM 42 or other MIDI device.
MIDI | MODE MEMORY
TRANSFR| SEND 1 SEND
Utility: MIDI Transfer
Page 4 of 6
Parameter Value Description
MODE
(Transfer
Mode)
SEND or
RECEIVE Set the transmitting unit to SEND,
set the receiving unit to RECEIVE.
MEMORY
1 to 16,
ALL Memory location to be sent /
received.
SEND /
RECEIVE (action is
flashing)
Select action and press ENTER to
begin transfer.
Transferring Memories between MM 42s
Connect the MIDI OUT/THRU of the transmitting MM
42 to the MIDI IN of the receiving MM 42.
Be sure the MIDI Rx and Tx of both units is not set to off.
On the receiving MM 42:
1. Set the receiving device to RECEIVE mode on the MIDI
TRANSFER page.
2. Select the MEMORY (1 through 16 or ALL) location in
which to store the incoming data.
3. Select the RECEIVE action (flashing) and press ENTER. The
following screen appears:
AWAITING MIDI DATA
PRESS CANCEL TO ABORT
On the transmitting MM 42:
1. Select SEND mode on the MIDI TRANSFER page.
2. Select the MEMORY (1 through 16 or ALL) location to send
to the receiving MM 42.
3. Select the SEND action (flashing) and press ENTER. The
sending MM 42 says SENDING MIDI DATA .
4. When incoming MIDI is detected the receiving MM 42 says
RECEIVING MIDI DATA .
5. When the transfer is complete both units display:
MIDI TRANSFER COMPLETE
PRESS CANCEL TO CONTINUE
If the following horrifying display appears on either unit
during the transfer there has been an error. Don't get mad, just
check all connections and settings and try again:
MIDI TRANSFER FAILED
PRESS CANCEL TO CONTINUE
Mode
When LATCH mode is selected, pressing the CUE BUS but-
ton once routes the MM 42’s signal to the Cue Bus and the front
panel PHONES jacks. Pressing the CUE BUS button again
removes the signal from the Cue Bus. It is possible (but poten-
tially confusing) to have multiple MM 42s active on the Cue Bus
at the same time. To avoid audio mayhem, always remember to
deactivate one MM 42 (by pressing its CUE BUS button) before
cueing another.
When MOMENTARY mode is selected the MM 42’s signal
is routed to the Cue Bus and front panel PHONES jacks only as
long as the CUE BUS button is pressed and held. Use this mode
once the mixes are fully dialed in and you just need to do the
occasional spot check.
Gain Reduction Meter Mode
GAIN |
REDUCTN| COMPRESSOR+LIMITER
Utility: Gain Reduction Meter
Page 2 of 6
Parameter Value Description
METER
MODE
COMPRESSOR
+ LIMITER
Displays maximum gain reduction
of all Compressor and Limiter
bands.
COMPRESSOR Displays maximum gain reduction
of all Compressor bands.
LIMITER
Displays maximum gain reduction
of all Limiter bands.
Important note: When the Compressor or Limiter is being
edited, the Gain Reduction meter automatically switches to display
the amount of gain reduction being applied to the currently selected
band of that processing section. At all other times the Gain Reduc-
tion meter follows the selected METER MODE in the UTILITY
menu.
MIDI Configuration
MIDI | Rx Tx MERGE/THRU
CONFIG | OMNI 1 off
Utility: MIDI Configuration
Page 3 of 6
Parameter Value Description
Rx
off, 1 to 16,
OMNI MIDI receive channel
Tx off, 1 to 16 MIDI transmit channel
MERGE/THRU off, ON MIDI merge/thru status
MIDI Rx (receive): in OMNI mode the MM 42 will respond
to MIDI data received on all MIDI channels.
MIDI MERGE/THRU: if MERGE/THRU is ON, incom-
ing MIDI data is merged with MIDI data from the MM 42 and
sent to the MIDI OUT/THRU port.
