Park Tool Co.

5115 Hadley Ave. N., St. Paul, MN 55128 (USA) www.parktool.com

BFS-1 Bottom

Bracket Facing Set

9

Part No.

Description

Qty.

678

Handle Weldment

1

674

Spring Retainer (not shown)

2

690

Facing Cutter

1

681

1.370 x 24 TPI Right Hand Bushing – English

1

682

1.370 x 24 TPI Left Hand Bushing – English

1

686

Knurled Washer

1

683

Anti-Rotation Washer

1

689

Pressure Spring

1

680

Tension Nut

1

688

36mm x 24 TPI Right Hand Bushing – Italian (Optional, 2 Required)

–

BFS-1 Part Numbers

1
2
3
4
5
6
7
8
9

© 2013 Park Tool Co.
PARK TOOL® and the color BLUE are
registered trademarks of Park Tool Co.

8

7

5

6

3

4

2

1
