PRODUCT DESCRIPTION
CircuitWorks

Water Soluble Flux Pen is
designed specifically to apply water soluble
flux with precision control. The Water
Soluble Flux consists of a neutral pH organic
water soluble flux compatible with most
solder masks. The high activity organic
product cleans easily with water, reducing
cleaning cost.
 pH neutral
 Completely portable package
 Cleans with water
 Excellent material compatibility
 Good soldering properties
 ORH1 Classification
TYPICAL APPLICATIONS
CircuitWorks

Flux Dispensing Pens
precisely dispense flux on:
 Printed Circuit Boards
 Chip Carriers
 Heat Sinks
 Surface Mount Device Pads
 Switches
 Sockets
TYPICAL PRODUCT DATA AND
PHYSICAL PROPERTIES
Water Soluble Flux Pen – CW8300
Flux Type Water Soluble
ORH1
Flash Point (TCC) 60
o
F (16
o
C)
pH 6.0 – 7.0
Appearance Yellow Liquid
Odor Slight
Shelf life 2 years
RoHS Compliant
RELIABILITY PROPERTIES
Copper Mirror Corrosion: High
Tested to J-STD-004, IPC TM-650, Method 2.3.32
Corrosion Test: High
Tested to J-STD-004, IPC-TM-650, Method 2.6.15
Silver Chromate: Fail
Tested to J-STD-004, IPC-TM-650, Method 2.3.33
Chloride and Bromides: 2.2%
Tested to J-STD-004, IPC-TM-650, Method 2.3.35
Fluorides by Spot Test: Pass
Tested to J-STD-004, IPC-TM-650, Method 2.3.35.1
SIR, IPC (typical): Pass
Tested to J-STD-004, IPC-TM-650, Method 2.6.3.3
CHEMTRONICS
Technical Data Sheet
CircuitWorks

Water Soluble Flux Pen
TDS #CW 8300
