PRODUCT DESCRIPTION

CircuitWorks

Silver Conductive Grease

provides maximum electrical and thermal
conductivity, proven lubrication properties,
and protection from moisture, oxidation,
and other environmental hazards. This
system utilizes an advanced silicone
lubricant that is compatible with metal,
rubber, and plastic.
 High electrical conductivity
 Excellent thermal conductivity
 Provides protection against wear
 Remains stable in a wide temperature

range; -70 to 485

°F (-57 to 252°C)

 Protects against moisture and corrosion
 Very low viscosity vs. temperature

change

TYPICAL APPLICATIONS
CircuitWorks

Silver Conductive Grease

may be used for high and low power
applications including:

 Lubrication of Substation Switches or

Circuit Breakers

 Heat Dissipation from Transformers
 Low or Medium Speed Sliding

Contacts

 Static Grounding on Seals or O-Rings
 Extending the Life of Rotating

Switches


TYPICAL PRODUCT DATA AND
PHYSICAL PROPERTIES

Composition

Material 100% Silver Filled
Silicone Grease
Color Silver/Gray

Consistency Smooth Paste

Properties

Volume resistivity <0.01 ohm-cm

Thermal Conductivity
(BTU-in/hr-ft

2

-

°F) 38.8

(CAL-cm/sec-cm

2

-

°C) 1.3 x 10

-2

( W/m

°K) 5.6

Operating Temperature -70 to 485

°F

Range (-57 to 252

°C)

Unworked Penetration 210
(ASTM D-1403) 77

°F

Worked Penetration 250
(ASTM D-1403, 60 Strokes)

Dropping Point 491

°F (255°C)

(ASTM D-2266)

Steel on Steel Wear 1.5mm
(ASTM D-2266)

Corrosion on Copper None

Moisture Resistance Excellent

Chemical Resistance Excellent

Electrical Conductivity Excellent

Thermal Conductivity Excellent

Lubrication Properties Excellent

Protection from Oxidation Excellent

Power Rating High/Low

Shelf life

2 years

RoHS Compliant

TDS # CW7100

CHEMTRONICS

Technical Data Sheet

CircuitWorks

Silver Conductive Grease
