Carrier PREMIERLINK 33CSPREMLK - Manual (Page 25)

25
Output 20 VDC at 25 mA
Feedback 0 (2)-10 or 6-9 VDC
Input 0 (2)-10 or 6-9 VDC, 0 (4)-20 mA
24 VAC/VDC
COM
(3)
(5)
(4)
(2)
(1)
J9-1
TO 24V
TRANSFORMER
Gray
White/Red
Red
Yellow
White
WIRE HARNESS
FROM ACTUATOR
ACTUATOR
50TJ400812
M9206-GGC-2
ECONOMIZER
12-PIN HARNESS
RED
24 VAC 1
2
3
4
5
BRN TRANSFORMER
GROUND
6
7
8
9
10
11
12
PNK
PL6
4-20mA TO
J9-1 ON
PREMIERLINK
CONTROLLER
12-PIN
FEMALE
MOLEX
CONNECTOR
12 8 4
11 7 3
2
1
6 10
9 5
CONNECTOR CABLE
Fig. 29 — PremierLink™ Controller Wiring to
Johnson Actuator With Wire Harness
(M9206-GGC-2)
Fig. 30A — PremierLink Control Wiring to Johnson Actuator Economizer Harness
